Input

Array size (integer; e.g., 4 to 64, 4 for 4×4, 64 for 64×64). K_on (S) (Scientific; e.g., 1e-9 to 1e-7). K_off = 1e-10 (S). K_on and K_off represent the memristor’s conductance levels in the ON (low-resistance) and OFF (high-resistance) states. The parameter K is, in some respects, analogous to the conductance of a linear resistor. V_dd (V) (Float; e.g., 1 to 3). Data Pattern (Float; e.g., 1: All Ones, 2: All Zeros). Connection Strategy (Float; e.g., 1: Floating Rows and Columns (FRC), 2: Grounded Rows with Floating Columns (GRFC), 3: Floating Rows with Grounded Columns (FRGC), 4: Grounded Rows and Columns (GRC) ). Interconnect Metal Layer (Float; e.g., 3: Metal 3, 5: Metal 5, 6: Metal 6 in IMEC A14. Please refer to reference [1] below for more details).

Result

No result yet.

Raw parsed values

—

Usage Count

Total computations done: loading ...

Copyright Notice and License

The copyright of this model is maintained by the developers. The model is distributed under the terms of the Creative Commons Attribution-NonCommercial 4.0 International Public License. If you use this model in your work, please cite reference [1].

Developers and Contact Information:

Developer: Zhenlin Pei ([email protected])

For technical or logistical inquiries, please contact Prof. Jinhui Wang at [email protected].

Development Team: Shah Zayed Riam, Zhenlin Pei, Kyle Mooney, Chenyun Pan, Na Gong, and Jinhui Wang.

Research Contribution

*Denotes equal contribution and co-first author
[1] S. Z. Riam*, Z. Pei*, K. Mooney, C. Pan, N. Gong, and J. Wang, “Sneak Path Current Modeling in Memristor Crossbar Arrays for Analog In-Memory Computing,” arXiv:2511.21796, 2025.
